Distinguishing feature

The clamp head adopts an advanced clamping mechanism, and the jaw plate and the tooth seat are separated. When clamping different columns, it is very convenient to replace the tooth block and tooth seat.

Two-speed variable speed, high-end speed, fast low-speed torque, to meet the needs of different pipe columns.

The clamp head brake mechanism is set on the clamp head cover plate, which is extremely convenient to adjust and maintain.

The new hydraulic back pliers are matched with the main pliers to form a combination pliers, and the manual commutation valve on the main pliers is operated. The back pliers are synchronously clamped with the main pliers or loosened the pipe column, which is flexible and reliable.

By adjusting the oil supply pressure, you can get the best torque required for the oil pipe of various steel grades.

It can be equipped with a hydraulic cylinder, and the cylinder valve is compactly connected with the manual reversing valve, which is easy to operate.

The torque control system can be selected to accurately control the buckle torque.
